Duplex Stainless Steel Condensate Pots

Home > Duplex Steel> Duplex Stainless Steel Condensate Pots

Anwar Tubefittings, located in Manama, Bahrain, stands out as a top manufacturer and supplier of high-quality Duplex Stainless Steel Condensate Pots. Known for their precision engineering, reliability, and resistance to corrosion, this company offers robust solutions tailored for both industrial and marine applications. Their Duplex Stainless Steel Condensate Pots are expertly designed to efficiently collect and separate condensate, ensuring that steam and fluid systems operate smoothly and safely. With a commitment to international standards and exceptional quality, Anwar Tubefittings provides customized solutions along with prompt service, making them a go-to partner for clients in need of high-performance components in demanding sectors like power, chemical, and oil and gas.

Duplex Stainless Steel Type A Condensate Pots with 2 Ports Manufacturer Manama, Duplex Stainless Steel Type B Condensate Pot with Red Oxide Coated Dealer Riffa , S31803 Duplex Stainless Steel Condensate Pots Type C Supplier Sitrah, 2205 Duplex Stainless Steel Type A Condensate Pot Exporter In Hamad Town, Duplex Stainless Steel Type B Condensate Pots with 3 Ports Manufacturer A'ali, Duplex Stainless Steel Type C Condensate Pot with Galvanized Plating Manama, Bahrain.

These Duplex Stainless Steel Condensate Pots are crafted from a well-balanced blend of austenitic and ferritic stainless steel, which gives them outstanding corrosion resistance and impressive mechanical strength. They are built to endure stress corrosion cracking, pitting, and general corrosion, even in harsh environments. On a mechanical level, these condensate pots boast high tensile strength, toughness, and fatigue resistance, ensuring they can reliably handle high pressure and temperature changes. The combination of durability, corrosion resistance, and mechanical integrity makes Duplex Stainless Steel Condensate Pots perfect for critical industrial and marine applications where long-lasting reliability is a must.

Duplex Stainless Steel Condensate Pots Specifications

Standard : DIN, ASTM, BS and all International Standards.
Number of Ports : 2 ports upto 8 ports, refer to the section below for arrangements.
Working Pressure : 6000 PSIG(41.34 MPa).
Pressure Rating : 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI.
Header Inlet : 1” Female Bsp or Npt threaded to ASME B16.1 or Flanged inlet optional.
Header Outlet/drain : None / or ¼”Male Bsp or Npt threaded to ASME B16.1 or 150# cast fitting.
Pipe size : 2″, 3″, 4″, 5”, 6” and larger size upon request.
Pipe Schedule : 40, 80, 160, XX seamless pipe.
Total Length : Pipe length 8″,10″,12″ and larger length upon request.
Thread Connections : NPT as per ANSI B1.20.1,Socket weld as per ANSI B16.11, Butt weld as per ANSI B16.9.

Sizing Of Duplex Stainless Steel Condensate Pots

P NPT – F	Capacity (Internal Vol.0)cm 3±5%	Pressure Rating PSIG	T mm	L mm	B mm
1/4”	150	1800	2.05	135	50.08
1/4”	300	1800	2.05	225	50.08
1/4”	400	1800	2.05	290	50.08
1/4”	500	1800	2.05	350	50.08
1/4”	1000	1800	4.06	275	88.09
1/4”	2250	1800	5.02	435	120
1/4”	3785	1800	5.02	680	120
1/2”	1000	1800	4.06	275	88.09
1/2”	2250	1800	5.02	435	102
1/2”	3785	1800	5.02	680	102
3/4”	1000	1800	4.06	275	88.09
3/4”	2250	1800	5.02	435	102
3/4”	3785	1800	5.02	680	102

Types of Duplex Stainless Steel Condensate Pots

Duplex Stainless Steel Type A Condensate Pot with Zinc Plating Price in Manama, DSS Type B Condensate Pots Supplier in Riffa , 2205 Duplex Stainless Steel Type C Condensate Pot Manufacturer in Sitrah, Duplex Stainless Steel Type A Condensate Pot with Galvanized Plating Manufacturer & Price in Hamad Town, Duplex Stainless Steel Condensate Pot Type B Supplier in A'ali, Duplex Stainless Steel Type C Condensate Pot with Red Oxide Coated In Manama, Bahrain.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Duplex Stainless Steel Condensate Pots in Manama, Bahrain

At Anwar Tube Fittings, We are proud to be the largest supplier, manufacturer, and exporter of Duplex Stainless Steel Condensate Pots in Manama, Bahrain Our cutting-edge solutions cater to all your piping needs. With state-of-the-art production facilities strategically located in the Bahrain, we maintain a vast inventory of over 16,000 tons of premium-quality materials, ensuring we have the stock readily available to meet your demands.

Duplex Stainless Steel Condensate Pots Uses

You’ll find Duplex Stainless Steel Condensate Pots widely utilized in industries that demand efficient condensate collection and protection for steam and fluid systems. They’re crucial in power plants, oil and gas facilities, chemical processing, and marine applications. These condensate pots effectively remove condensate from steam lines, helping to prevent water hammer and maintain operational efficiency. Their ability to resist corrosion and mechanical stresses guarantees longevity and dependable performance, even in tough conditions. By merging durability, corrosion resistance, and operational efficiency, Duplex Stainless Steel Condensate Pots truly shine in their roles across various demanding industries.
