Anwar Tubefittings stands out as a top-notch manufacturer and supplier of high-performance Hastelloy Tube Fittings, proudly based in Manama, Bahrain. The company has built a solid reputation for delivering products that are not only exceptional in quality but also precision-engineered to meet the needs of industries that require outstanding corrosion resistance and dependable fluid handling solutions. Their Hastelloy Tube Fittings are crafted to excel in tough environments, guaranteeing leak-free connections and a long lifespan. With state-of-the-art manufacturing facilities and rigorous quality standards, Anwar Tubefittings consistently offers fittings that align with global specifications. Their dedication to innovation, durability, and customer satisfaction has established them as a trusted name in Bahrain’s industrial and engineering landscape.
Hastelloy Tube Fittings are made from nickel-based superalloys, celebrated for their remarkable corrosion resistance, particularly in acidic, high-temperature, and oxidizing settings. These fittings boast impressive mechanical properties, such as high tensile strength, excellent thermal stability, and robust resistance to pitting, stress corrosion cracking, and wear. Thanks to precision machining, they ensure accurate dimensions, secure sealing, and durability even under varying pressures. Their strong composition and mechanical integrity make Hastelloy Tube Fittings perfect for demanding fluid and gas handling tasks across a range of industries.
| Hastelloy Tube Fittings specification (ASTM / ASME) | ASTM B366, ASME SB366 |
|---|---|
| Working Pressure | Up to 6,000 psi (based on severity of application) |
| Two-Ferrule Tube Fittings | Pressure Ratings : Up to 11 000 psig (760 bar) |
| Medium-Pressure, Gaugeable | Pressure Ratings: Up to 20 000 psig (1378 bar) Temperature Ratings: Up to 1000°F (537°C) |
| High-Pressure Hastelloy C276 Tube Fittings | Pressure Ratings: Up to 60 000 psig (4134 bar) Temperature Ratings: Up to 1000°F (537°C) Materials of construction: 316 Stainless Steel Tube Fittings, Alloy 2507, Inconel 625 Tube fittings |
| Hastelloy Tube Fittings Special sizes | 22mm Hastelloy C276 tube fittings 25mm Hastelloy C22 tube fittings 32mm Hastelloy B2 tube fittings 50mm Hastelloy Ferrule tube fittings |
| Hastelloy Compression Fittings End Connections | Types: NPT, ISO/BP, SAE/MS, AN, weld ends, port connectors, sanitary flanges, tube adapters |
| Hastelloy C276 Tube Fittings Sizes | 1/16 to 2 in.; 2 to 50 mm 1/4, 3/8, 1/2, 9/16, 3/4 in.; 6, 10, 12 mm |
| Brand Name | Hastelloy Tube fittings |
| Configurations | Straights, elbows, tees, crosses, caps, plugs, nuts and ferrules Chromatograph and Column End |
| Types | Unions, NPT, medium-pressure cone and thread adapters, male SAE/MS, reducers, port connectors, tube adapters, caps, plugs |
| Hastelloy Hydraulic Fittings Specification | Items Made from Hex – ASTM B574 ; Items made from Round Bar- ASTM B564 |
| Tube Size | 1/16”OD to 2”OD, 2mm OD to 50mm OD |
| Threads | NPT (ANSI B1.20.1), BSP, BSPT (ISO thread configurations), UNF, SAE etc. |
| PTFE Standards | ASTM D1710, ASTM D3294 |
| Hastelloy Ferrule Tube Fittings Applicable Temperature | 150-400°C |
| Hastelloy C276 Tube Fittings Packing Details |
|
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
| C22 | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min* | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
| B2 | 0.02 max | 1.0 max | 0.1 max | 0.03 max | 1.0 max | Bal | 1.0 max | 2.0 max | 26 – 30 | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
| Hastelloy B2 | 9.2 g/cm3 | 1370 °C (2500 ºF ) | Psi – 1,10,000 , MPa – 760 | Psi – 51000 , MPa – 350 | 40 % |
At Anwar Tube Fittings, we are the largest supplier, manufacturer, and exporter of Hastelloy Tube Fittings in Manama, Bahrain. Our advanced manufacturing facilities, strategically positioned in the Bahrain, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfill your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.
| OD Size: 6mm to 38mm | Inch: 1/4″ to 1 1/2″ |
Contact us to get a quick quote for your requirement.
Anwar Tube Fittings is a leading supplier and stockist of premium Hastelloy Tube Fittings in Manama, Bahrain. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.
These fittings are widely utilized in sectors where top-tier corrosion resistance and high mechanical strength are crucial for system reliability. You’ll often find them in chemical processing plants, petrochemical units, offshore platforms, and oil and gas operations, thanks to their ability to endure aggressive media. They also play a vital role in pharmaceutical manufacturing, pollution control systems, marine engineering, and power generation facilities. Their capacity to maintain leak-proof performance under extreme temperatures and pressures makes them ideal for critical fluid transfer operations.
Please feel free to contact us if you need any further information or for enquiry.
