Incoloy 825 Tube Fittings

Home > Incoloy > Incoloy 825 Tube Fittings

Anwar Tubefittings, a reputable manufacturer and supplier based in Manama, Bahrain, focuses on providing top-notch Incoloy 825 Tube Fittings that are built to resist corrosion and last over time. With a strong reputation for precision engineering and compliance with international standards, this company delivers fittings that excel in tough environments. Their Incoloy 825 Tube Fittings are well-regarded for their strength, leak-proof connections, and extended lifespan. Catering to sectors like petrochemical, oil and gas, marine, and chemical processing, Anwar Tubefittings guarantees dependable solutions that can handle the rigorous demands of high-temperature and corrosive applications throughout Bahrain and the Gulf region.

Incoloy 825 Instrumentation Tube Fittings Supplier in Manama, Incoloy 825 Double Ferrule Tube Fittings Price List in Riffa , Nickel Alloy Twin Ferrule Fittings Manufacturer in Sitrah, Incoloy 825 Single Ferrule Fittings In Hamad Town, Incoloy 825 Bulkhead Union, Incoloy 825 Ferrule Fittings Exporter in Riffa , Incoloy 825 Instrumentation Fittings Manufacturer in A'ali, Incoloy 825 Compression Tube Fittings in Manama, Bahrain.

These Incoloy 825 Tube Fittings are crafted from a nickel-iron-chromium alloy, enhanced with molybdenum, copper, and titanium, which gives them remarkable resistance to pitting, stress corrosion cracking, and oxidation. The alloy boasts impressive mechanical properties, including high tensile and yield strength, along with excellent stability in both acidic and alkaline settings. These fittings are reliable even under high temperatures and pressures, ensuring strong and secure connections. Their outstanding metallurgical stability and resistance to chloride-induced corrosion make them ideal for challenging industrial environments.

Incoloy 825 Tube Fittings Specifications

Material Test Certificates (MTC) for Tube Fitting as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175
Specifications	ASTM B366 / ASME SB366
Size	1/16 in. to 2 in. & 2mm to 50 mm.
Dimensional Range	1/16 to 2 inches (imperial); 2 to 50 mm (metric)
Working Pressures	Upto 2000 to 8250 PSI
Thread Type	NPT – ASME B1.20.1, SAE AS71051 \| ISO/BSP Parallel – ISO 228 \| ISO/BSP Tapered – ISO 7, BS EN 10226-1 \| SAE (Unified) – ASME B1.1
End Connections	NPT, ISO/BP, SAE/MS, AN, weld ends, port connectors, sanitary flanges, tube adapters
Types	Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories
Equivalent To	SWAGELOK, PARKER, DK-LOK, HOKE
Max Working Pressure	8MPa \| 1200psi Depending on The Tubing Material
Working Temperature	-40°C—250°C \| -40°F—482°F Depending on The Tubing Material
Configurations	Straights, elbows, tees, crosses, caps, plugs, nuts and ferrules Chromatograph and Column End
Tube Fitting uses & application	Compression tube fitting to connect two imperial tubes (or fractional tubes), two metric tubes or, also, the connection of a metric tube at one end and a fractional/imperial tube at the other end in Petroleum, Power, Chemical, Construction, Gas, Metallurgy, Shipbuilding etc Tube Fittings useful for their extreme temperature and pressure capabilities for high/low temperatures applications, and their compatibility with aggressive fluids, compression fittings can be seen in systems varying from gas lines in refineries, plumbing etc.

Incoloy 825 Tube Fittings Chemical Composition

Grade	C	Mn	Si	S	Al	Ti	Fe	Ni	Cr
Incoloy 825	0.10 max	0.50 max	0.50 max	0.015 max	0.40 max	0.40 max	5.0 max	58.0 min	20.0 – 23.0

Incoloy 825 Tube Fittings Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
8.4 g/cm3	1350 °C (2460 °F)	Psi – 1,35,000 , MPa -930	Psi – 75,000 , MPa – 517	42.5 %

Types of Incoloy 825 Tube Fittings

Incoloy 825 Tube Fittings Equivalent Grades

STANDARD	UNS	WNR.	AFNOR	EN	JIS	BS	GOST	OR
Incoloy 825	N08825	2.4858	NC22DNB4M	NiCr22Mo9Nb	NCF 825	NA 21	ЭП703	ЭИ602

Incoloy 825 Bulkhead Union, Incoloy 825 Alloy Tube To Union, Incoloy 825 Instrumentation Tube Fittings Price in Manama, Incoloy 825 Male Branch Tee Supplier in Riffa , Incoloy 825 Bulk Head Female Connector Manufacturer in Sitrah, Incoloy 825 Single Ferrule Tube Fittings Price in Hamad Town, Incoloy 825 Male Run Tee Supplier And Manufacturer in A'ali, Incoloy 825 Male Elbow In Manama, Bahrain.

Largest Manufacturer and Supplier of Incoloy 825 Tube Fittings in Manama, Bahrain

At Anwar Tube Fittings, we are proud to be the largest supplier, manufacturer, and exporter of Incoloy 825 Tube Fittings in Manama, Bahrain. Our cutting-edge solutions cater to all your piping needs. With state-of-the-art production facilities strategically located in the Bahrain, we maintain a vast inventory of over 16,000 tons of premium-quality materials, ensuring we have the stock readily available to meet your demands.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Incoloy 825 Tube Fittings Uses

Incoloy 825 Tube Fittings find their place in various industries where resistance to severe corrosion and high temperatures is crucial. They are frequently used in chemical processing plants, acid production facilities, and pickling equipment due to their capability to endure aggressive chemicals. In the oil and gas industry, you’ll find them on offshore platforms, in sour gas systems, and during subsea operations. Power generation plants utilize these fittings for heat exchangers and boiler systems. Moreover, they play a vital role in marine engineering, pollution control systems, pharmaceuticals, and nuclear fuel reprocessing, ensuring long-lasting performance and safety in operations.
