Monel Condensate Pots

Home > Monel >Monel Condensate Pots

Monel Condensate Pots are top-notch vessels crafted to efficiently gather and eliminate condensate from steam, gas, and various fluid lines in industrial setups. Made from Monel alloy, these pots boast remarkable resistance to corrosion, oxidation, and chemical damage, ensuring they deliver reliable service even in tough conditions. They’re designed to safeguard downstream equipment like valves, pumps, and turbines by preventing issues such as water hammer, erosion, and contamination. You’ll find Monel Condensate Pots in power plants, chemical processing facilities, marine systems, and oil & gas operations, where durability, efficiency, and safety are paramount.

Monel Type A Condensate Pot with Galvanized Plating Manufacturer Manama, Monel® Alloy Type B Condensate Pot with Zinc Plating Dealer Riffa , Monel Type C Condensate Pots with 4 Ports Dealers Sitrah, Monel Type A Condensate Pots with 2 Ports Exporter In Hamad Town, UNS N04400 Type B Condensate Pots Exporter In A'ali, Monel Type C Condensate Pot with Zinc Plating Exporter In Manama, Bahrain.

These pots are primarily made from a nickel-copper alloy, which gives them outstanding resistance to corrosion from acids, alkalis, and seawater. On the mechanical side, they show excellent tensile strength, toughness, and resistance to fatigue and thermal cycling. The material’s stability at high temperatures and in aggressive environments ensures that the pots maintain their structural integrity and consistent performance over time. This blend of mechanical strength and corrosion resistance makes Monel Condensate Pots incredibly dependable for continuous-duty and high-pressure applications, helping to minimize maintenance and operational downtime.

Monel Condensate Pots Specifications

Standard : DIN, ASTM, BS and all International Standards.
Number of Ports : 2 ports upto 8 ports, refer to the section below for arrangements.
Working Pressure : 6000 PSIG(41.34 MPa).
Pressure Rating : 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI.
Header Inlet : 1” Female Bsp or Npt threaded to ASME B16.1 or Flanged inlet optional.
Header Outlet/drain : None / or ¼”Male Bsp or Npt threaded to ASME B16.1 or 150# cast fitting.
Pipe size : 2″, 3″, 4″, 5”, 6” and larger size upon request.
Pipe Schedule : 40, 80, 160, XX seamless pipe.
Total Length : Pipe length 8″,10″,12″ and larger length upon request.
Thread Connections : NPT as per ANSI B1.20.1,Socket weld as per ANSI B16.11, Butt weld as per ANSI B16.9.

Chemical Compositions Of Monel Alloy Condensing Pot

Grade	C	Mn	Si	S	Cu	Fe	Ni
Monel Alloy Condensing Pot	0.30 max	2.00 max	0.50 max	0.024 max	28.00 – 34.00	2.50 max	63.00 min

Sizing Of Monel Alloy Condensing Pot

P NPT – F	Capacity (Internal Vol.0)cm 3±5%	Pressure Rating PSIG	T mm	L mm	B mm
1/4”	150	1800	2.05	135	50.08
1/4”	300	1800	2.05	225	50.08
1/4”	400	1800	2.05	290	50.08
1/4”	500	1800	2.05	350	50.08
1/4”	1000	1800	4.06	275	88.09
1/4”	2250	1800	5.02	435	120
1/4”	3785	1800	5.02	680	120
1/2”	1000	1800	4.06	275	88.09
1/2”	2250	1800	5.02	435	102
1/2”	3785	1800	5.02	680	102
3/4”	1000	1800	4.06	275	88.09
3/4”	2250	1800	5.02	435	102
3/4”	3785	1800	5.02	680	102

Top Monel Condensate Pots Manufacturing Company in Manama

At Anwar Tube Fittings, we are the largest supplier, manufacturer, and exporter of Monel Condensate Pots in Manama, Bahrain. Our advanced manufacturing facilities, strategically positioned in the Bahrain, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Monel Condensate Pots

Monel Condensate Pot Type A Price in Manama, Monel Type B Condensate Pot with Red Oxide Coated Manufacturer Supplier in Riffa , Monel Condensate Pot Type C Manufacturer in Sitrah, Monel® Alloy Type A Condensate Pot with Red Oxide Coated Price in Hamad Town, K500 Monel Condensate Pots Type B Manufacturer in A'ali, 400 Monel Type C Condensate Pot Dealer In Manama, Bahrain.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Monel Condensate Pots Supplier in Manama, Bahrain

Anwar Tube Fittings is a leading supplier and stockist of premium Monel Condensate Pots in Manama, Bahrain. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Monel Condensate Pots Uses

Monel Condensate Pots are essential in scenarios where effective condensate removal and protection of downstream equipment are crucial. They’re typically installed in steam and condensate lines within power generation plants, the chemical and petrochemical sectors, offshore and marine systems, and various industrial process lines. These pots help prevent corrosion, water hammer, and damage to sensitive equipment while ensuring the system operates efficiently. With their sturdy construction, corrosion resistance, and reliability, Monel Condensate Pots are vital for maintaining safe, efficient, and long-lasting performance in critical fluid-handling and steam systems.
