These Duplex Steel Hydraulic Fittings are crafted from a well-balanced austenite-ferrite microstructure that’s enriched with chromium, nickel, molybdenum, and nitrogen. This unique composition grants them excellent resistance to corrosion, stress cracking, and wear. On the mechanical side, these fittings showcase high tensile and yield strength, outstanding toughness, and reliable fatigue performance, even in high-pressure and low-temperature scenarios. They are engineered to endure intense hydraulic pressures, vibrations, and mechanical stress, ensuring a leak-proof and long-lasting operation. The blend of chemical and mechanical properties makes Duplex Steel Hydraulic Fittings the go-to choice for critical hydraulic systems in tough industrial environments.
These Duplex Steel Hydraulic Fittings are crafted from a well-balanced austenite-ferrite microstructure that’s enriched with chromium, nickel, molybdenum, and nitrogen. This unique composition grants them excellent resistance to corrosion, stress cracking, and wear. On the mechanical side, these fittings showcase high tensile and yield strength, outstanding toughness, and reliable fatigue performance, even in high-pressure and low-temperature scenarios. They are engineered to endure intense hydraulic pressures, vibrations, and mechanical stress, ensuring a leak-proof and long-lasting operation. The blend of chemical and mechanical properties makes Duplex Steel Hydraulic Fittings the go-to choice for critical hydraulic systems in tough industrial environments.
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | DUPLEX 2205 |
| SERIES | LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE |
| WORKING PRESSURE | 1 BAR TO 700 BAR |
| SIZE RANGE | 6 MM TO 42 MM |
| CONNECTIONS | TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE |
| WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH |
ELEMENT | DUPLEX 2205 | DUPLEX 31803 |
|---|---|---|
NI | 4.50 – 6.50 | 4.50 – 6.50 |
C | 0.030 max | 0.030 max |
MN | 2.00 max | 2.00 max |
P | 0.030 max | 0.030 max |
S | 0.20 max | 0.020 max |
SI | 1.00 max | 1.00 max |
CR | 21.0 – 23.0 | 22.0 – 23.0 |
MO | 2.50 – 3.50 | 3.0 – 3.5 |
N | 0.08 – 0.20 | 0.14 – 0.20 |
FE | 63.54 min | 63.72 min |
| Grade | YS (MPa) | UTS (MPa) | % Elongation | Hardness(BHN) |
| 31803 | 450 min. | 620 min. | 25 min. | 293 max. |
| 2205 | 450 min. | 655 min. | 25 min. | 293 max. |
| Density (Kg.m-1) | 7810 |
| Magnetic Permeability | <50 |
| Young’s Modulus (N/mm2) | 190 x 10^3 |
| Specific Heat, 20°C (J.Kg-1.°K-1) | 400 |
| Specific Electrical Resistance, 20°C (µO.m) | 0.85 |
| Thermal conductivity, 20°C | 15 |
| Mean coefficient of thermal expansion | 11 x 10^-6 |
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Duplex 2205 Plate | 1.4462 / 1.4462 | UNS S31803 / UNS S32205 |
Contact us to get a quick quote for your requirement.
These fittings are widely utilized in industries that demand high-pressure fluid control and dependable performance. They play a crucial role in hydraulic systems for oil and gas operations, chemical processing, and heavy machinery. In the realms of power generation and marine engineering, these fittings guarantee safe and efficient fluid transfer under challenging conditions. Their corrosion resistance, high strength, and durability against fatigue make them ideal for high-pressure pipelines, hydraulic cylinders, and instrumentation lines.
