Anwar Tubefittings, located in Manama, Bahrain, has built a solid reputation as a reliable manufacturer and supplier of high-quality piping and instrumentation components, including Monel Hydraulic Fittings. With a focus on precision engineering and a commitment to international quality standards, the company serves a variety of industries such as oil and gas, petrochemical, chemical processing, marine, offshore engineering, and power generation. Their Monel hydraulic fittings are crafted to ensure leak-proof connections, outstanding mechanical strength, and remarkable corrosion resistance, even in the toughest environments. Anwar Tubefittings consistently provides robust, high-performance solutions that guarantee the safe and dependable operation of hydraulic systems in critical industrial settings.
Monel Hydraulic Fittings are composed primarily of nickel (63-70%) and copper (29-33%), with small amounts of iron, manganese, and other elements to enhance strength and durability. These fittings exhibit impressive mechanical properties, including high tensile strength (up to 620 MPa) and excellent ductility, making them suitable for high-pressure applications. The advantages of Monel fittings include exceptional resistance to corrosion, especially in seawater, acidic, and alkaline environments. They perform well under extreme temperatures and pressures, ensuring reliability and longevity. These properties make Monel fittings ideal for marine, oil & gas, chemical processing, and other demanding industries.
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | MONEL 400, MONEL K500 |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| CONNECTIONS | TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE |
| WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH |
| Designation | C% | Co% | Cr% | Mo% | Ni% | V% | W% | Ai% | Cu% | Nb/Cb Ta% | Ti% | Fe% | Sonstige Autres-Other % |
| Monel 400 | 0.12 | – | – | – | 65.0 | – | – | – | 32.0 | – | – | 1.5 | Mn 1.0 |
| Monel 401 | 0.10 | – | – | – | 43.0 | – | – | – | 53.0 | – | – | 0.75 | Si 0.25; Mn 2.25 |
| Monel 404 | 0.15 | – | 52.0-57.0 | – | – | 0.05 | rest/bal | – | – | 0.50 | Mn 0.10; Si 0.10;S o.024 | ||
| Monel 502 | 0.10 | – | – | – | 63.0-17.0 | – | – | 2.5-3.5 | rest/bal | – | 0.50 | 2.0 | Mn 1.5;Si 0.5; S 0.010 |
| Monel K 500 | 0.13 | – | – | – | 64.0 | – | – | 2.8 | 30.0 | – | 0.6 | 1.0 | Mn 0.8 |
| Monel R 405 | 0.15 | – | – | – | 66.0 | – | – | – | 31.0 | – | – | 1.2 | Mn 1.0; S 0.04 |
| Tensile strength, Ultimate | 550 Mpa |
| Tensile strength, Yield | 240 Mpa |
| Elongation at Break | 48% |
| Color/appearance | Gray [6] |
| Luster | Metallic [9] |
| Melting point | 1300 – 1350°C [1] |
| Density | 8.80X103 kg/m3 [2] |
| State of matter at room temperature (normal phase) | Solid [9] |
| Hardness | 110-150 HB [7] |
| Thermal Conductivity | 21.8 W/(m K) [1] |
| Resistivity | 54.7X10-8 ohm-m [2] |
| Tensile strength (annealed) | 550 MPa [2] |
| Specific heat capacity | 427 J/(kg*K) [2] |
| Modulus of elasticity | 179 GPa [2] |
|
STANDARD
|
WERKSTOFF NR.
|
UNS
|
JIS
|
BS
|
GOST
|
AFNOR
|
EN
|
|
Monel 400
|
2.4360
|
N04400
|
NW 4400
|
NA 13
|
МНЖМц 28-2,5-1,5
|
NU-30M
|
NiCu30Fe
|
|
Monel K500
|
2.4375
|
N05500
|
–
|
–
|
–
|
–
|
–
|
The Monel Hydraulic Fittings are made from nickel-copper alloys like Monel 400 and Monel K500, which are known for their excellent resistance to seawater, acids, alkalis, and chloride stress corrosion cracking. These alloys boast high tensile and yield strength, exceptional toughness, and durability under high pressures and temperature fluctuations. The precision-machined fittings ensure secure connections, minimal leakage, and reliable fluid transfer, even in harsh chemical or marine conditions. Their corrosion-resistant features make them perfect for hydraulic systems that face extreme challenges.
Contact us to get a quick quote for your requirement.
These fittings find extensive use in offshore oil and gas platforms, desalination plants, marine vessels, chemical and petrochemical facilities, and power generation plants. They facilitate safe and efficient hydraulic fluid transfer, safeguard sensitive equipment from leaks and pressure drops, and uphold system integrity under severe conditions. Monel Hydraulic Fittings are the go-to choice for engineers and industrial clients who demand top-notch corrosion resistance, mechanical reliability, and long-lasting performance. Their sturdy construction and high-alloy composition make them a dependable option for various applications.
Monel Hydraulic Fittings are widely used in industries requiring high corrosion resistance and durability. In marine applications, they are essential for handling seawater and salt-laden environments, ensuring leak-proof connections in hydraulic systems. In the oil and gas industry, these fittings provide reliable performance in high-pressure and high-temperature operations, especially in offshore drilling. They are also employed in chemical processing plants, where resistance to acids, alkalis, and harsh chemicals is crucial. Additionally, Monel fittings are suitable for aerospace and power generation industries, offering excellent strength and longevity in challenging conditions, making them ideal for demanding hydraulic applications.
Please feel free to contact us if you need any further information or for enquiry.
